Key electrical specs

• Energy: 2.56 kWh.
• Nominal voltage: 12.8 V, operating range 11.2–14.4 V (some retail specs list 10.8–14.6 V).
• Capacity: 200 Ah.
• Recommended charge/discharge current: ≤120 A, recommended discharge power ≤1 500 W.
• Max charge/discharge current (15 s): 200 A, max power 2 500 W for 15 s.

Lifetime, protection and integration

• Chemistry: LiFePO₄ (Lithium Iron Phosphate).
• Depth of discharge: ≥95% DOD.
• Cycle life: ≥6 000 cycles @ 25 °C, 80% DoD.
• Mounting: floor‑mounted metal case, about 522 × 238 × 218 mm, ≈23 kg.
• BMS & safety: built‑in intelligent BMS with over‑charge, over‑discharge, over‑current, short‑circuit and temperature protection.
• Scalability: up to 16 units in parallel (40.96 kWh total); up to 4 in series if used in higher‑voltage banks.

Typical applications

FLA12200 is suited to small 12 V solar or backup setups – loads like lights, routers, small fridges, camping/backup trolleys, RVs or small inverters – where compact 2.56 kWh storage, long life and deep cycling are required, and additional units can be added later if needed
